Masterlam 3.0

Products

Masterlam 3.0

The Masterlam 3.0 is an automatic, single-plate Ø 250 to 300mm polishing machine with bidirectional rotation and variable speed. It also has touch screen controls, an intuitive and user-friendly interface and is equipped with parameter storage and expert technologies.

The unit is equipped with a powerful central and invidual pressure head, bidirectional rotation, variable speed and pressure. The distinctive feature of the polishing head is the oscillation function, with oscillation configurable both for amplitude and frequency.

Using the Masterlam 3.0, polishing can be carried out with central pressure or individual pressure and can be equipped with a stock removal measuring system.

The Masterlam 3.0 is based on the same technology as the Masterlam 1.0 with a powerful central and individual pressure head equipped with 6 pistons. Changing sample holders is quick and the pressure mode is controlled directly on the screen without having to touch the head, therefore making it easier to switch from one pressure mode to another in a few seconds.

Speed, direction and duration are programmable via an easy to use touch screen and the unit is equipped with a USB port for simple saving and loading of programs.

The optional dispensing unit is a 3 unit doser powered by 3 peristaltic pumps connected to 1 external pump. It is programmed via a touch screen and connected to the Masterlam 1.1 with a simple connection.

Further options include:
Automatic Dispenser DISTRILAM – 4 Pumps + Plate Cleaning
Recirculation/Sedimentation Tank with Pump

Central pressure mode

Individual pressure mode

Loading...
Product
Masterlam 3.0
Automatic, single plate 250 to 300 mm polishing machine, bidirectional rotation and variable speed.
no. B6317

Specifications

Specifications

Plate capacity Ø 250 to 300 mm
Body Steel coated with epoxy paint
Bowl Removable resin bowl for easy cleaning
Controls Touch screen (5,7“)
Plate rotation speed Variable from 20 to 650 rpm Bidirectional rotation
Head’s speed Variable from 10 to 150 rpm Bidirectional rotation
Applicable load 5 to 400 N central pressure 5 to 100 N individual pressure
Capacity Sample size 6 X Ø 40 mm Sample size 1 – 6 X Ø 50 mm
Workspace lightening LED
Water inlet Removable pipe, with flow rate adjustment and safety solenoid valve
Programming 60 storable programs, USB connector to backup programs and Ethernet port for networking
Cumulative machine power 1.1 kW
Voltage 230 V – 50 Hz single phase
Pneumatic feed 6 bars
Dim. W x H x D 550 x 670 x 580 mm
Weight 85 kg
Technical Note

Technical Note

Download Technical Note

[pdf-embedder url=”https://localhost/loeneninstruments/wp-content/uploads/2021/08/masterlam3_0-EN.pdf”]

Order

Art.Description Unit PriceQuantity
B6317

Auto Polisher MASTERLAM 3.0 Combo Pressure

 Each p.o.r.
B6390-M3

Recirculation/Sedimentation Tank with Pump

 Each p.o.r.
B6392-M3

Cover for SMARTLAM 2.0 or MASTERLAM 1.0, 2.0 & 3.0

 Each p.o.r.
B6422-M3

Transparent Safety Canopy for MASTERLAM 1.0, 2.0, 3.0

 Each p.o.r.
B6389-3

Automatic Dispenser DISTRILAM – 4 Pumps + Plate Cleaning

 Each p.o.r.
Brand:

Accessories

Loading...
Product
Dosing unit DISTRILAM
The automatic dosing unit DISTRILAM is directly controlled via the touch screen on the machine
no. 60 MLD00 00

Description

The automatic dosing unit DISTRILAM is directly controlled via the touch screen on the machine through a RS 232 connector. It is instantly recognised by all the MASTERLAM polishing devices as the control program is already programmed in the machines. It is equipped with 4 circuits composed of 3 standard peristaltic pumps for an accurate dosage of diamond liquids, and 1 high flow rate peristatic pump for the dosage of the lubricant or the colloidal silica abrasive. It works without compressed air nor electric wiring. The automatic dosing unit DISTRILAM is an indispensable accessory for an automatic use of the MASTERLAM.

This device is the guarantee of a reproducible process and an economic use of the fluids.

It contains: a dosing unit, a machine connection, a 4 ways distribution nozzle on magnetic leg and 4 plastic bottles.

Dimensions W x H x D : 170 x 205 x 200 mm

Order

Art.Description Unit PriceQuantity
60 MLD00 00

Dosing unit DISTRILAM

 Each p.o.r.
Brand:

Product
Sample holder for irregular part
160 mm central pressure sample holder for eccentric restriction of non-embedded complex geometric parts.
no. 06 MLC60 00

Order

Art.Description Unit PriceQuantity
06 MLC60 00

Sample holder for irregular part

 Each p.o.r.
Brand:

Product
IP sample holder
For machine MASTERLAM3.0 IP 160 mm with 6 x 50 mm water cells
no. 06 MLI10 00

Order

Art.Description Unit PriceQuantity
06 MLI10 00

IP sample holder

 Each p.o.r.
Brand:

Product
Aluminium plate Ø250 mm
no. 08 8270300

Order

Art.Description Unit PriceQuantity
08 8270300

Aluminium plate Ø250 mm

 Each p.o.r.
Brand:

Product
Aluminium plate Ø300 mm
no. 08 827040

Order

Art.Description Unit PriceQuantity
08 827040

Aluminium plate Ø300 mm

 Each p.o.r.
Brand:

Product
Filtering / decantation 60 L tank
For machines MASTERLAM1.0, 3.0 & 1.1
no. 60 A0029 90

Order

Art.Description Unit PriceQuantity
60 A0029 90

Filtering / decantation 60 L tank

 Each p.o.r.
Brand:

Product
Filtering / sedimentation 60 L tank + recirculation pump
For machines MASTERLAM1.0, 3.0 & 1.1 With pump controlled by the machine.
no. 60 A0029 00

Order

Art.Description Unit PriceQuantity
60 A0029 00

Filtering / sedimentation 60 L tank + recirculation pump

 Each p.o.r.
Brand:

Product
Transparent protective housing
The secured housing is a totally transparent protection
no. AGB6392

Description

The secured housing is a totally transparent protection compatible with the full range of MASTERLAM. Its opening stops all movements of the machine*, it offers
an integral protection complying with the 2006/42/ CE and 2004/108/CE standards.

The housing s design preserves the accessibility of the plate and does not clutter the workspace.

The touch screen is located outside of the secured zone; therefore, the commands are permanently accessible.

*However, the transparent secured housing authorises the plate rotation in the manual mode.

For machines MASTERLAM1.0 & 3.0
For the MASTERLAM1.0 and 3.0 the touch screen control panel is located on the right, a 195 mm space needs to be foreseen in addition to the machine width.

Space: width 770 mm, height 910 mm
For machine MASTERLAM1.1
Space: width 880 mm, height 910 mm
